Submersible pump Tsurumi KTZ 45.5

Tsurumi Pump
Catalogue number: IKZ4IHRD
EAN: 4944792111543
Price on request
Availability:  Temporarily unavailable
Shipping time:  on requesti The shipping time for this product is determined individually.

Please contact Customer Service
Warranty: 1 year
Comments: 0
Add commentiThe Seller does not verify the added statements (opinions, comments or any other statements), in particular, does not verify them in terms of whether they come from Customers who have purchased and used the Products.

Related products

Technical characteristics

Cable lenght
20 m
Pressure resistance
25 m
Maximum solid handling
8,5 mm
Maximum performance
1740 l/min
Maximum height lift
22,5 m
Engine power
5,5 kW / 7,5 KM
Connector diameter
100 mm
Application
Woda czysta
Weight
82 kg
Current
11,4 A (znamionowy)

DETAILED SPECIFICATION


  Submersible pump Tsurumi
Specification Pump
Components Impeller Semi-open type impeller
Bearings Shielded ball bearings
Shaft seal Double mechanical seal
Material Impeller Chromium iron casting
Casing Grey iron casting EN-GJL-200
Suction plate Ductile iron casting EN-GJS-500-7
Shaft seal Silicon carbide in oil bath
Specification Motor
Material
Casing Grey iron casting EN-GJL-200
Shaft Stainless steel EN-X30CR13
Cable Rubber − NSSHÖU
Frequency 50 Hz
Voltage 400 V (three-phase)
Built-in motor protection Circle thermal cut-out
Type Induction motor, 2 poles
Insulation Insulation class F
Lubrication Turbine oil − ISOVG32
Protection IP 68
Specification Pumping Fluid
Medium type Spring water, rain water, ground water, sand carrying water
Temperature 040° C
Specification Other
ø Discharge bore mm 100 mm
Discharge Connection Threaded flange / Hose coupling
All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement.
Submersible pump Tsurumi KTZ 35.5
Engine power 5.5 kW, lifting height 32 m, capacity 1100 l/min, connection diameter 3''
Price on request
Submersible pump Tsurumi KTZ 415
Engine power 15 kW, lifting height 55 m, capacity 1980 l/min, stub diameter 4″, dirt diameter 12 mm
Price on request
Submersible pump Tsurumi KTZ 615
Engine power 15 kW, lifting height 39.5 m, capacity 2800 l/min, 6″ discharge port, 20 mm diameter of impurities
Price on request
Submersible pump Tsurumi KTZ 422
Engine power 22 kW, lifting height 71,5 m, capacity 4000 l/min, 4'' discharge port, 8.5 mm diameter of impurities
Price on request
Submersible pump Tsurumi KTZ 622
Engine power 22 kW, lifting height 55 m, capacity 4000 l/min, 6'' discharge port, 12 mm diameter of impurities
Price on request
