Submersible pump TSURUMI HS 2.75S
Variant description: Engine power 0.75 kW, lifting height 18 m, performance 230 l/min
Technical characteristics
DETAILED SPECIFICATION
Submersible pump Tsurumi | ||
Specification | Pump | |
Components | Impeller | Semi-vortex impeller |
Bearings | Shielded ball bearings | |
Shaft seal | Double mechanical seal | |
Material | Impeller | Urethane rubber |
Casing | Ductile iron casting EN-GJS-700-2 | |
Suction plate | – | |
Shaft seal | Silicon carbide in oil bath | |
Specification | Motor | |
Material | Casing | Aluminium die casting |
Shaft | Stainless steel EN-X6CR13 | |
Cable | Rubber − H07RN-F | |
Frequency | 50 Hz | |
Voltage | 230 V (single phase) | |
Built-in motor protection | Miniature protector | |
Type | Induction motor, 2 poles | |
Insulation | Insulation class E | |
Lubrication | Turbine oil − ISOVG32 | |
Protection | IP 68 | |
Specification | Pumping Fluid | |
Medium type | Spring water, rain water, ground water, sand carrying water | |
Temperature | 0 − 40° C | |
Specification | Other | |
ø Discharge bore mm | 50 mm | |
Discharge Connection | Threaded flange / Hose coupling |
advantages
- The spiral pump body with a large cross-section allows easy transport of sand and other deposits. The engine is well cooled so that the pump can run dry for a long time,
- Side outflow – the spiral flow makes pumping water with sand or sediment without any problems. The pump runs dry safely even when it is partially submerged or when it draws in air,
- Long service life and simple operation,
- The pump body is resistant to abrasion. Access to the rotor is possible after unscrewing only three screws,
- Newly developed engine – the aluminium motor body is lightweight and provides proper cooling.
