Manual screed Jazon LR3m 3 m
Related products
Fastening screw for Jazon manual screed
Fastening screw for Jazon manual screed
The Jazon LR3m screed works best where you need to quickly level or profile large surfaces. All elements are galvanized and powder coated, which protects against corrosion and facilitates cleaning after work.
After assembling the appropriate elements, different working lengths are available, which can later be precisely adjusted thanks to the special joining of the slat (bean-shaped holes). Thanks to the modernized height adjustment, we can smoothly adjust the height (depth) of the staff using cranks, also thanks to which it is easier to set the required slope.
The strip moves on two ebonite rollers. Guides (optional equipment) or curbs can be used for sliding. Perfect for laying pavements and housing estate roads. Thanks to the height-adjustable slat, we can adapt it to curbs or guides.
Technical characteristics
Set contains
- Roller pair
- 70 cm, 80 cm, 180 cm long slats,
- A set of connectors for connecting slats,
- A pair of handles to pull the slat,
- Strip with special height adjustment.
Sample set of 6 m guides on two sides *
- 4x guide 3m
- 6x foot
- 6x saddle
Assembly variants
| Variant I | |
| Module | 70 cm |
| Smooth regulation | 88 - 96 cm |
| Variant II | |
| Module | 80 cm |
| Smooth regulation | 98 - 106 cm |
| Variant III | |
| Module | 180 cm |
| Smooth regulation | 198 - 206 cm |
| Variant IV | |
| Module | 70 + 80 cm |
| Smooth regulation | 136 - 152 cm |
| Variant V | |
| Module | 70 + 180 cm |
| Smooth regulation | 236,5 - 252 cm |
| Variant VI | |
| Module | 80 + 180 cm |
| Smooth regulation | 231 - 247 cm |
| Smooth regulation | 246 - 262 cm |
| Variant VII | |
| Module | 70 + 80 + 180 cm |
| Smooth regulation | 269,1 - 292,9 cm |
| Smooth regulation | 284,1 - 307,9 cm |
