Catalogue number: 1.286-932.0
EAN: 4054278164977
Comments: 0
Add commentiThe Seller does not verify the added statements (opinions, comments or any other statements), in particular, does not verify them in terms of whether they come from Customers who have purchased and used the Products.Technical characteristics
Tension
400 V (three-phase)
Frequency
50 Hz
Maximum flow rate
650 – 1300 l/h
Working pressure
30 – 180 bar / 3 – 18 MPa
Pressure maximum
198 bar / 19,8 MPa
Medium temperature
60 °C
Engine power
9.2 kW / 12.5 KM
Sound Pressure Lpa
72 dB(A)
Sound pressure level uncertainty
2 dB(A)
Noise level
87 dB(A)
Vibration level
< 2.5 m/s²
Vibration uncertainty
0.3 m/s²
Amount of oil
1,2 l
Resistance class
IP X5
Hose length
10 m (high pressure)
Length x Width x Height
560 x 500 x 1090 mm
Weight
75.5 kg (with package), 70 kg (with accessories)
All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement.
